Caster Tips

Caster tips have the advantages of uniform molten aluminium flow, laminar flow, no blockage, and the same temperature in the caster tip outlet.

Share

Description

It is made of alumina ceramic fibers and binders through special processes. It has the advantages of uniform molten aluminium flow, laminar flow, no blockage, and the same temperature in the caster tip outlet.

Performance

ItemunitMeasured valueInspection standard
densityKg/m3460GB/T25139-2010
Maximum service temperature≥1200GB/T25139-2010
expansivity700℃2.1x10-6GB/T5072-2008
Thermal conductivityw/m.k      ≤0.14(700℃)GB/T5072-2008
Shrinkage coefficient700℃x12h≤0.5GB/T5072-2008
compression strengthMPa≥0.16GB/T5072-2008
Fe2o3%0.14GB/T6900-2006
TiO2%0.40GB/T6900-2006
caO%0.17GB/T6900-2006

Advantages

  1. High strength, good elasticity, no deformation, long service life
  2. High precision, smooth surface, used for high-quality rolling
  3. Uniform fiber distribution, good insulation performance
  4. Wear resistance, high temperature resistance, erosion resistance, no slag;No chemical reaction with molten aluminium
  5. Strong carbonation resistance, complete specifications, comprehensive cost-effective.
  6. Self-produced fiber,strict quality control
  7. Automatic production line,high accuracy

Application

Used for aluminium foil, strip,sheet roll casting.

  • High temperature preheating is required to thoroughly dry the caster tips and low the thermal expansion.
  • Preheated by the baking box with circulatory ventilation is suggested.
  • Heating temperature 140 -180 ℃.
  • Preheating time:4 hours.
  • It should be used in time after preheating. Otherwise need to preheat again.
