Performance

Features

1. Produced by 120 meters roller kiln, fully automated production line
2. High strength, no slag, good thermal shock resistance;
3. High porosity, small filtration resistance, high surface energy, heterophase adsorption capacity, no pollution to molten aluminium
4. Good stability when molten aluminium pass
5. Various specifications, can provide 7-inch to 26-inch also can be customized according 20PPI to 70PPI;
6. Three different types of sealing gasket: fiber paper , fiber cotton and expandable

Advantages

Use more 4-5 times than other CFF in case of Electrical heating1.26Mpa compressive strength higher than other CFF 0.6-1MPa
Usage

• Clean the filter box before use a filter
• Gently place the CFF into the filter box slot and press the sealing around to prevent side flow.
• Uniformly preheat the filter box and CFF to make them close to the molten aluminium temperature
• Preheated by electric or gas Under normal circumstances: 15-30min.
• Make launder full of molten aluminium during filtration, avoid striking and vibrating
• After the filtration, take out the filter plate in time and clean the filter box.
